PROFITEST PRIME AC Test instrument for testing the effectiveness of protective measures in electrical installations per IEC 60364-6, machines and systems per IEC 60204-1, low-voltage switchgear and controlgear assemblies per DIN EN 61439-1, PV systems per DIN EN 62446-1 and electric charging stations per DIN EN 61851-1.PROFITEST PRIME AC is a test instrument for testing the effectiveness of protective measures in electrical installations per IEC 60364-6, machines and systems per IEC 60204-1, low-voltage switchgear and controlgear assemblies per IEC 61439-1, PV systems per DIN EN 62446-1 and electric charging stations per DIN EN 61851-1.

Item number: M506H

Measurement in AC/DC systems

Measurement of internal system resistance and fault loop resistance with high test current up to 690 V AC / 800 V DC without tripping RCD types A and B

Low-resistance measurement for protective and equipotential bonding conductors with 200 mA, as well as automatic polarity reversal and 25 A

Testing of RCD types A, AC, F, B, B+, EV, MI and G/R, as well as SRCDs and PRCDs

Combined RCD test with continuously rising ramp, time to trip, tripping current

Insulation measurement up to 1000 V with rising ramp

Testing of RCMs and IMDs

Measurement of leakage and differential current

Measurement of temperature and humidity

Voltage measurement, 1000 V AC/DC

High-voltage testing: 2.5 kV AC, 500 VA, standard sequence, ramp function and pulse control mode

Work safety concept for the inspector in accordance with DIN EN 50191 and EN 61557-14 with indicator lamp, emergency stop switch and key switch

Mains and battery operation (with limited functionality)

Bluetooth and USB interfaces

Push-print function – transmission of the measured value after measurement

Intuitive operation

Efficient work

Standards-compliant testing

Legally secure documentation

As single test instrument for a broad range of applications

All measurements without any bothersome replugging of the measurement cables

Interchangeable test tips on the measurement cables

Can be used all over the world thanks to language selection

Future-proof thanks to firmware updates

10-year service guarantee

DAkkS certificate issued by own calibration laboratory

User support for questions about testing

Cascadable, future-proof software concept

Modern data management by means of customer and measurement data administration

Creation of system structures – from the system all the way down to the measuring points

Quick and easy generation of a legally secure report per ZVEH

Easy operation with rotary switch

Predefined test sequences for structured testing

Coded plugs assure error-free testing

On-site help thanks to help function with wiring diagrams

Measuring category: 600 V CAT III / 300 V CAT IV

4-wire measuring method – no compensation of the measurement cables is required

Standards-compliant testing of the effectiveness of protective measures in electrical installations per DIN VDE 0100-600, machines and systems per VDE 0113-1, low-voltage switchgear and controlgear assemblies per VDE 0660-600-1, PV systems per VDE 0126-23 and electric charging stations per VDE 0122-1.

Broad-range measuring device for all alternating and 3-phase electrical systems with voltages of up to 1000 V and frequencies of 15.4 to 420 Hz

Low-resistance measurement for protective and equipotential bonding conductors with 200 mA, as well as automatic polarity reversal and 25 A

Insulation measurement up to 1000 V with rising ramp

Measurement of internal system resistance and fault loop resistance with high test current up to 690 V AC / 800 V DC without tripping RCD types A and B

Testing of RCD types A, AC, F, B, B+, EV, MI and G/R, as well as SRCDs and PRCDs

Combined RCD test with continuously rising ramp, time to trip, tripping current

Testing of RCMs and IMDs

Measurement of leakage and differential current

Measurement of temperature and humidity

Voltage measurement, 1000 V AC/DC

High-voltage testing: 2.5 kV AC, 500 VA, standard sequence, ramp function and pulse control mode

Mains and battery operation (with limited functionality)

Bluetooth and USB interfaces

Push-print function – transmission of the measured value after measurement

The PROFITEST PRIME AC makes your investment decision easy because standards-compliant testing can be conducted on electrical installations per IEC 60364-6, on machines and systems per IEC 60204-1, on low-voltage switchgear and controlgear assemblies per IEC 61439-1, on PV systems per DIN EN 62446-1 and on electric charging stations per DIN EN 61851-1 with the accessories which are perfectly matched to the requirements.
Shenzhen Yinfei Company is offering the PROFITEST PRIME AC, a multifunctional electrical safety tester, for sale.
